26mm Three Hours Fire Rated Paint For Structural Steel Polyester Based Metal Grey
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Color: | Gray | Appearance: | Powder |
|---|---|---|---|
| Dosge: | 16kg/㎡ | Thickness: | 26mm |
| Fire Rate: | Three Hours | Application: | Steel, Metal |
| High Light: | passive fire protection products,fire proofing paint |
||
26mm Three Hours Fire Rated Paint For Structural Steel Polyester Based Metal Grey
Product Description
Thickness steel structure fireproof coating powder coating paint
The product is made of high strength binder, high temperature resistant material, heat insulation material and so on. It has strong adhesion force and good fireproof performance, and replace the two-component construction process of the cementitious fireproof paint, which make construct process easier.
| Dry Density(kg/m3) | 300-400µ |
| State | Powder and emulsion mixed |
| Based | cementitious ,polyester |
| Fireproof Grade | B1 |
| Fireproof time | 3-4H |
| Thickness | 26mm |
| Hard Dry Time | 8H |
| Adhesion Strength(Mpa) | 0.14 |
| Compressive Strength(Mpa) | 1.0 |
| Water Resistance(h) | 24 |
| Freeze-thaw Resistance | Done 15 times without any defects |
| Color | White,Grey |
Range of application
Indoor and outdoor steel materials used in factories, warehouses,airport, etc
Main Features
Excellent fireproofing performance
Stable physical and chemical properties
Good adhesion force, hard to produce peeling
Construction process
Step 1 -Substrate treatment: remove the rust&dust on the steel
Stpe 2 -Primer: coat primer
Step 3 -Fireproof paint: paint 3-4 times after the former coat, primer is totally dried(24hours)
Engineering Case
Chengdu Four Points Hotel
Packaging & Shipping
FAQ
How/Where to Use
What Are The Most Common Applications For Zhuoan’s Fireproof Coating?
The most common applications for Zhuoan’s Fireproof Coating are in the building industry. Historic architecture,wood cottage, furniture,lumber, OSB, polywood, wood fire resistant coating top the list. Hotel, hospital, theater, school ,airport, mall, factory are also a common usage with steel fire resistant coating.
Can Zhuoan’s Fireproof Coating Be Applied Over Existing Rust And Corrosion?
With wood Fireproof Coating,the substrate surface must be clean,dry and free from contamination, such as dust,oil stain,water stain,etc.With steel Fireproof Coating, only a NACE 3 / SSPC-SP 6 commercial blast cleaning is typically necessary.
Application and Training
What Does The Preparation Process Entail?
Only a NACE 3 / SSPC-SP 6 commercial blast cleaning is typically necessary. There is no need to blast to NACE 1 or 2 since slight oxidation on the surface allows for the best chemical reaction.
Can The Speed Of Reaction Be Slowed Down To Increase Working Time Before It Is Cured?
There are various ways to decrease reaction time, but they are specific to the material being coated and environmental factors. We will advise you on this during the consultation.
What Thickness Is Recommended?
For wood Fireproof Coating,11.81mils; for steel Fireproof Coating, 118.11~1968.5mils, specific to the material being coated and fire resistant standard.
Do I Need Special Equipment In Order To Apply Zhuoan’s Fireproof Coatings?
Zhuoan’s fireproof coating applied using a plural (2K) spray gun or brush or roller. For spray model, the coating uses specific ratio, and sprays on using standard plural spray equipment that mixes at the nozzle of the spray gun. The process requires no heating equipment or other apparatus besides the plural spray gun.
What Does The Certification Process Entail?
Training is at our facility or yours. We teach you how to use it, the application process, and how to recognize proper effect. Experienced painters generally pick up the technique and understand the minor differences in a few minutes. We recommend two days of training to allow ample time to cover maintenance of the equipment, trouble shooting, and to understand the technology.
Who Can Apply Zhuoan’s Fireproof Coatings?
Zhuoan’s Fireproof Coatings can be applied by either:
• An Zhuoan’s Fireproof Coatings certified contractor
• Product manufacturers who have been trained by Zhuoan
If Overspray Happens On Adjacent Surfaces Can It Be Easily Removed?
Zhuoan’s Fireproof Coatings can only be removed by sandblast or grit media. Our training team will educate your staff on the process to minimize overspray.
Purchasing Zhuoan’s Fireproof Coatings
There may be an Zhuoan’s Fireproof Coatings distributor near you.
If you are unable to find a distributor or certified applicator near you, please contact us so that we can arrange direct shipment to you.
How Do I Buy Fireproof Coatings?
Zhuoan’s Fireproof Coatings can be purchased through an Zhuoan distributor or by contacting us directly.
